1. Thickness |
| Product | Total Thickness | Structure | |||
| FEP | CR Film | FEP | |||
| 150FCR019 | 0.038mm | - | 25um | 12.5um | |
| 200FCR919 | 0.050mm | 12.5um | 25um | 12.5um | |
2. Properties |
| No. | Item | Unit | 150FCR019 | 200FCR919 | |||
| 1 | Corona resistance life (1 KV voltage, frequency 20 KHztemperature 90 ±2oC pulse rise time 400 ns ) | hours | ≥80 | ≥80 | |||
| 2 | Industrial frequency electric intensity | v/um | ≥120 | ≥100 | |||
| 3 | Surface resistivity | Ω | 1X1014 | 1X1014 | |||
| 4 | Volume resistivity | Ω. Cm | 1X1010 | 1X1010 | |||
| 5 | Relative permittivity (48-62 Hz ac) | - | 3.2±0.4 | 3.2±0.4 | |||
| 6 | Dielectric power factor (48-62 Hz ac) | - | ≤3.5X10-3 | ≤3.5X10-3 | |||
| 7 | Tensile strength | Mpa | ≥80 | ≥80 | |||
| 8 | Elongation at break | % | ≥40 | ≥40 | |||
| 9 | Stripping force | N/25mm | ≥6 | ≥10 | |||
| 10 | Hot shrinkage rate | % | |||||
| 150oC, 0.5h | ≤1.0 | ≤1.0 | |||||
| 400oC, 0.5h | ≤3.0 | ≤3.0 | |||||
